Stationary Phase Cable Assemblies

Low Loss Cable Assemblies
Stationary Phase Cable Assemblies
High Performance Cable Assemblies
General Cable Assemblies

<Upper layer

Stationary Phase Cable Assemblies

Stationary Phase Cable Assemblies More Products

· Stationary Phase Cable Assemblies

Home > Productos > Alta Frecuencia > Cable Assemblies

Pimary Performance of Some Typical Cable Assemblies

Part Number of Cable Assemblies	Frequency Range	VSWR	Flexural Phase Stability	Temperature Phase Stability	Insertion Loss dB Max
WXZ102SMAJ/SMAJ XXXX	0~20 GHz	≤ 1.30	≤ 3°(10GHz)	≤ 500PPM	Standard Attenuation +2 × 0.06 f(GHz)
WXZ102SMAJ/SMJK XXXX	0~20 GHz	≤ 1.35
WXZ204SMKJ/SMKJ XXXX	0~40 GHz	≤ 1.30
WXZ204SMKJ/SMKK XXXX	0~40 GHz	≤ 1.35
WXZ601NJ/NJ XXXX	0~18 GHz	≤ 1.25
WXZ601 NJ/NK XXXX	0~18 GHz	≤ 1.30

Typical VSWR Performance of WXZ601 NJ/NJ0500 Cable Assembly
