Special Type Optical Cable
Technical Characteristics
• Fiber count: 2~144
• Low loss, low dispersion
• Proper design and precise excess length control offer superior mechanical and environmental properties to cable.
• A longitudinal wrap of double-side filmed corrugated aluminum tape is bonded tightly to the PE sheath, which ensures the radial moistureproof performance of cable.
• Double steel wire armor enhances cable's side pressure and tensile resistance capability.
Performance
• Applicable to long distance communication, inter-exchange communication, CATV, computer network transmission system, etc.
• Minimum bend radius: Static 15D, dynamic 30D.
• Operation temperature: -40~+70℃.
