Feature
• Soft, flexible, easy to handle.
• Suitable for indoor cabling system.
• Suitable for pigtail fiber and jumper wire.
• Suitable for optical connection in optical communication machine room, optical distribution frame, optical device/equipment, etc.
• Good mechanical and environmental performance.
• Excellent flame retardance property and easy to strip.
• Jacket material can be flame retardant PVC, LSZH flame retardant polyolefin, TPU or other agreed material.
• Customized design is available.
Technical Parameter
| Fiber Count | Cable Size (mm) | Cable Weight (kg/km) | Tensile Load (N) | Crush Load (N/100mm) | Temperature Range (℃) |
||
|---|---|---|---|---|---|---|---|
| Long-term | Short-term | Long-term | Short-term | ||||
| 2 | 2.5 | 5 | 60 | 100 | 100 | 500 | -20~+60 |
| 2 | 3.0 | 7 | 60 | 100 | 100 | 500 | |
| 2 | 3.2 | 8 | 80 | 150 | 100 | 500 | |
| 2 | 3.6 | 10 | 100 | 200 | 200 | 1000 | |
| 2 | 4.2 | 16 | 150 | 300 | 200 | 1000 | |
| 2 | 4.5 | 18 | 200 | 400 | 200 | 1000 | |
Note: 1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20D under dynamic bending and 10D
under static bending; for B6 fiber, 10D (dynamic) and 5D (static). (D is overall diameter of round cable)
2． All the data in the table are for reference and subject to change without notification
