Flat Optical-fiber-ribbon 2 More Products

Feature

• Good mechanical and environmental performance.

• Flame retardance meets relevant standards.

• Suitable for indoor cabling and lead-into-building cable.

• Suitable for pigtail fiber and jumper wire.

• For optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.

• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin or other agreed materials.

• Customized design is available.

Technical Parameter

Fiber Count	Cable Size (mm)	Cable Weight (kg/km)	Tensile Load (N)		Crush Load (N/100mm)		Temperature Range (℃)
Fiber Count	Cable Size (mm)	Cable Weight (kg/km)	长期	短暂	长期	短暂	Temperature Range (℃)
4	2.5×3.5	9	80	200	200	500	-20~+60
6	2.5×4.0	11	80	200	200	500
8	2.5×4.5	12	80	200	200	500
12	2.5×5.0	14	80	200	200	500

Note：1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20H under dynamic bending and

10H under static bending; for B6 fiber, 10H (dynamic) and 5H (static). (H is the minor axis height of the flat cable.)

2. All the data in the table are for reference and subject to change without notification.
