Feature

• Good mechanical and environmental performance.

• Flame retardance meets relevant standards.

• Support high-capacity data transmission.

• Suitable for indoor horizontal cabling.

• Suitable for  pigtail fiber, jumper wire, and optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.

• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin or other agreed materials.

• Customized design is available.

Technical Parameter

Fiber Count  Cable Size
(mm)
Cable Weight
(kg/km)
Tensile Load
(N)
Crush Load
(N/100mm)
Temperature Range
(℃)
Long-termShort-termLong-termShort-term
4 5.0 20 120 300 200 1000 -20~+60
6 5.2 22 120 300 200 1000
8 5.5 26 150 350 200 1000
12 6.5 36 200 500 200 1000

Note: 1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20D under dynamic bending and 10D

under static bending; for B6 fiber, 10D (dynamic) and 5D (static). (D is overall diameter of round cable)

2. The data of cable size and weight are calculated according to ф0.9 tight buffered fiber.

3. All the data in the table are for reference and subject to change without notification.
