Feature
• Good mechanical and environmental performance.
• Flame retardance meets relevant standards.
• Support high-capacity data transmission.
• Suitable for indoor horizontal cabling.
• Suitable for pigtail fiber, jumper wire, and optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.
• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin or other agreed materials.
• Customized design is available.
Technical Parameter
| Fiber Count | Cable Size (mm) | Cable Weigh (kg/km) | Tensile Load (N) | Crush Load (N/100mm) | Temperature Range (℃) |
||
|---|---|---|---|---|---|---|---|
| Long-term | Short-term | Long-term | Short-term | ||||
| 14 | 11 | 102 | 450 | 850 | 300 | 1000 | -20~+60 |
| 16 | 12 | 121 | 500 | 950 | 300 | 1000 | |
| 18 | 12.7 | 133 | 550 | 1000 | 300 | 1000 | |
| 20 | 13.6 | 156 | 600 | 1100 | 300 | 1000 | |
| 22 | 14.5 | 168 | 650 | 1200 | 300 | 1000 | |
| 24 | 15.5 | 185 | 700 | 1300 | 300 | 1000 | |
Note: 1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20D under dynamic bending and 10D
under static bending; for B6 fiber, 10D (dynamic) and 5D (static). (D is overall diameter of round cable)
2. The data of cable size and weight are calculated according to ф2.0 single-fiber cable.
3. All the data in the table are for reference and subject to change without notification.
